2-641238-0
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Rectangular Connector Panel Mount
PDF
/
Inventory: 9090
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-2
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.275 inch
Plating Thickness 30μin
Contact Finish Thickness 30.0μin 0.76μm
Technical
Wire Size (Max) 22 AWG
Wire Size (Min) 28 AWG
Contact Design PREASSEM CONN
Wire Type Discrete or Ribbon Cable
Cable Termination IDC
Wire/Cable Gauge 24 AWG
Wire/Cable Type Discrete
Dielectric Withstanding Voltage 750VAC V
ELV Non-Compliant
Body/Shell Style PLUG
Insulation Resistance 5000000000Ohm
Wire Gauge 24 AWG
Contact Resistance 5mOhm
Rated Current (Signal) 4A
Body Depth 0.275 inch
Operating Temperature (Min) -55°C
Body Breadth 0.52 inch
Shrouding No
Body Length or Diameter 2 inch
Reliability COMMERCIAL
Voltage - Rated AC 250V
Contact Finish Gold
Reference Standard UL, CSA
Total Number of Contacts 20
Pitch 0.100 2.54mm
Contact Type Female Socket
Subcategory Headers and Edge Type Connectors
Fastening Type Locking Ramp
Number of Rows 1
Color White
Number of Positions 20
Connector Type Receptacle
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Closed End
Series MTA-100
Published 2013
Packaging Bulk
Physical
Housing Material Nylon
Mounting Type Free Hanging (In-Line), Right Angle
Mount Free Hanging
Contact Material PHOSPHOR BRONZE
