643815-9
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings 9P 26AWG TIN CLSD W/TAB WHT W/BLU STRP
PDF
/
Inventory: 1964
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating Lead, Tin
Mount Cable, Free Hanging
Housing Material Nylon
Technical
Packaging Bulk
JESD-609 Code e0
Pbfree Code no
Termination IDC
Connector Type Connector, Receptacle, Socket
Max Operating Temperature 221°C
Min Operating Temperature -67°C
Color Blue
Number of Rows 1
Fastening Type Ramp
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Depth 6.99mm
Current Rating 5A
Reference Standard UL
Voltage - Rated AC 250V
Reliability COMMERCIAL
Approval Agency CSA
Shrouding No
Lead Pitch 2.54mm
Number of Contacts 9
Mating Information MULTIPLE MATING PARTS AVAILABLE
Body Breadth 0.275 inch
Contact Gender Female
Housing Color Blue, White
Contact Style SQ PIN-SKT
Contact Resistance 6mOhm
ELV Non-Compliant
Max Voltage Rating (AC) 250V
Polarization Key POLARIZED HOUSING
Dielectric Withstanding Voltage 750VAC V
Wire/Cable Type Discrete
Durability 25 Cycles
Wire/Cable Gauge 26 AWG
Contact Pattern RECTANGULAR
Insulation Diameter 1.52 mm
Contact Rating (Current) 5A
Dimensions
Height 6.99mm
Length 22.86mm
Plating Thickness 5.08μm
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-2
Lead Free Not Applicable
