M80-5D12605M2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 5728
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material NOT SPECIFIED
Mounting Type Panel Mount
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Technical
Packaging Bulk
Series Datamate J-Tek
Feature Jackscrews, Polarizing Key
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Header
Number of Positions 26
Color Black
Number of Rows 2
HTS Code 8536.69.40.40
Fastening Type Threaded
Contact Type Male Pin
Pitch 0.079 2.00mm
Total Number of Contacts 26
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 1.417 inch
Contact Gender FEMALE
Operating Temperature (Min) -55°C
Body Depth 0.309 inch
Wire Gauge 22 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Body/Shell Style PLUG
Durability 500 Cycles
Cable Termination Crimp
Wire Type Discrete
Compliance
RoHS Status ROHS3 Compliant
