M80-5D12005M2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Free Hanging Rectangular Connector
PDF
/
Inventory: 7748
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Wire Type Discrete
Cable Termination Crimp
Durability 500 Cycles
Body/Shell Style PLUG
Row Spacing 0.079 (2.00mm)
Insulation Resistance 100000000Ohm
Wire Gauge 22 AWG
Body Depth 0.309 inch
Operating Temperature (Min) -55°C
Contact Gender FEMALE
Body Length or Diameter 1.181 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Total Number of Contacts 20
Pitch 0.079 2.00mm
Contact Type Male Pin
Fastening Type Threaded
HTS Code 8536.69.40.40
Number of Rows 2
Color Black
Number of Positions 20
Connector Type Header
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Jackscrews, Polarizing Key
JESD-609 Code e4
Series Datamate J-Tek
Packaging Bulk
Physical
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Type Panel Mount
Contact Material NOT SPECIFIED
