M80-4801605
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
PANEL MOUNTABLE Free Hanging Rectangular Connector
PDF
/
Buying Options
Total Price: USD $17.27
Unit Price: USD $17.2744
≥1 USD $17.2744
≥10 USD $15.12984
≥100 USD $14.476352
≥500 USD $14.009248
≥1000 USD $13.54232
≥3000 USD $12.79513
Inventory: 86
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mounting Type Free Hanging (In-Line)
Insulation Material GLASS FILLED POLYPHENYLENE SULPHIDE
Mounting Option 1 LOCKING
Technical
Packaging Bulk
Published 2015
Series Datamate J-Tek
JESD-609 Code e4
Feature Jackscrews
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Receptacle
Number of Positions 16
Color Black
Number of Rows 2
Gender Female
Additional Feature PANEL MOUNTABLE
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Female Socket
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 16
Orientation Straight
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Operating Temperature (Min) -55°C
UL Flammability Code 94V-0
Rated Current (Signal) 3A
Wire Gauge 22 AWG
Insulation Resistance 100000000Ohm
Row Spacing 0.079 (2.00mm)
Polarization Key POLARIZED HOUSING
Durability 500 Cycles
Cable Termination Crimp
Wire Type Discrete
Contact Design LOOSE
Dimensions
Contact Finish Thickness 11.8μin 0.30μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
