350557-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Contacts
Description
CONN SOCKET 16-18AWG TIN CRIMP
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
≥10 USD $0.18128
≥100 USD $0.168256
≥500 USD $0.159632
≥1000 USD $0.15092
≥3000 USD $0.140554
Inventory: 1783
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length 25.53mm
Height 3.56mm
Technical
Cable Entry-Max 0.115 inch
VDE Tested No
Assembly Item Name CONTACT
Pin or Socket Socket
Insulation Diameter 2.921 mm
Contact Termination Crimp
Circuit Application Power
Contact Current Rating 15A
Wire/Cable Gauge 18 AWG
Wire Gauge (Min) 16 AWG
Wire Gauge (Max) 18 AWG
Wire/Cable Type Discrete
Connector Support Type CONNECTOR ACCESSORY
Max Current Rating 15A
ELV Compliant
Wire Gauge 16-18 AWG
Operating Supply Voltage 250V
Contact Gender Female
Approval Agency UL
Contact Finish Tin
Current Rating 13A
Depth 3.56mm
Shielding Unshielded
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Voltage - Rated 250V
Min Operating Temperature -67°C
Max Operating Temperature 221°C
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Commercial MATE-N-LOK
Published 1997
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 19 Weeks
