146479-4
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 04 MODII HDR SRST UNSHRD STKG
PDF
/
Inventory: 9761
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Mount Through Hole
Mounting Type Through Hole
Insulation Material THERMOPLASTIC
Technical
Packaging Bulk
Published 2011
Series AMPMODU Mod II
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Connector Type BOARD STACKING CONNECTOR
Number of Positions 4
Color Black
Number of Rows 1
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 4
Current Rating 3A
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Number Of PCB Rows 1
PCB Contact Pattern RECTANGULAR
Body Breadth 0.092 inch
Contact Gender MALE
Operating Temperature (Min) -65°C
Contact Finish - Post (Mating) Gold
Contact Style SQ PIN-SKT
Insulation Resistance 5000000000Ohm
Body/Shell Style RECEPTACLE
Dielectric Withstanding Voltage 750VAC V
Contact Pattern RECTANGULAR
Dimensions
Length 33.782mm
Length - Stack Height 0.670 17.018mm
Length - Overall Pin 1.330 33.782mm
Length - Post (Mating) 0.330 8.382mm
Contact Finish Thickness - Post (Mating) 15.0μin 0.38μm
Length - Tail 0.330 8.382mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
