146481-5
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
05 MODII HDR SRST UNSHRD STKG
PDF
/
Inventory: 4272
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Stack Height 25.4mm
Length - Tail 2.54mm
Length - Termination 0.33 inch
Contact Finish Thickness - Mating 381 nm
Technical
Stackable Yes
Contact Rating (Current) 3A
Mating Post Length 8.38mm
Contact Pattern RECTANGULAR
ELV Non-Compliant
Body/Shell Style RECEPTACLE
Insulation Resistance 5GOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Lead Length 36.32mm
Housing Color Black
UL Flammability Code 94V-0
Contact Gender MALE
Body Breadth 0.092 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 5
Number Of PCB Rows 1
Body Length or Diameter 2.484 inch
Approval Agency CSA
Reliability COMMERCIAL
Number of Conductors ONE
Current Rating 3A
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Subcategory Headers and Edge Type Connectors
Additional Feature AMPMODU
Number of Rows 1
Min Operating Temperature -65°C
Max Operating Temperature 125°C
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Through Hole
Pbfree Code no
JESD-609 Code e0
Physical
PCB Mount Retention Without
PCB Mounting Orientation Vertical
Mounting Style STRAIGHT
Housing Material Thermoplastic
Contact Shape Square
Mounting Type BOARD
Contact Plating Gold
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
