EP12SD1AQE

C&K
RoHS
RoHS RoHS compliant
Package /
Category Switches / Pushbutton Switches
Description SWITCH PUSHBUTTON SPDT 1A 120V
PDF
/
Inventory: 1177
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks

Physical

Contact Plating Silver
Mount Through Hole
Mounting Type Through Hole, Right Angle
Material Glass, Nylon
Housing Material Nylon
Actuator Material Glass, Nylon, Polyester, Thermoplastic

Technical

Operating Temperature -30°C~85°C
Packaging Tray
Published 2010
Series EP
Feature Epoxy Sealed Terminals
Part Status Active
Termination PC Pins
Type Standard
Power Rating 400mW
Voltage - Rated DC 28V
Current Rating (Amps) 1A AC/DC
Orientation Right Angle
Ingress Protection IP57 - Dust Protected, Waterproof
Depth 19.2mm
Current Rating 1A
Termination Style PC Pin
Voltage - Rated AC 120V
Actuator Type Round, Plunger
Circuit SPDT
Switch Function On-Mom
Color - Actuator/Cap Black
Max Voltage Rating (AC) 120V
Max Current Rating 1A
Electrical Life 30,000 Cycles
Max Voltage Rating (DC) 28V

Dimensions

Height 5.08mm
Length 9.27mm
Width 8.13mm
Actuator Length 5.46mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Ratings IP57, Waterproof
