ITNF-0239-D202
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Pulse Transformers
Description
Pulse Transformers ITNF PULSE TRANSFORM THT 0.17A
PDF
/
Buying Options
Total Price: USD $7.51
Unit Price: USD $7.507162
≥1 USD $7.507162
≥140 USD $2.996038
≥560 USD $2.896257
≥980 USD $2.846367
Inventory: 2933
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 22.3mm
Length 22.7mm
Height Seated (Max) 0.535 13.60mm
Technical
Pulse Rise Time-Max 1500ns
ET Product-Min 350 V-us
Turns Ratio - Primary:Secondary 1:01
Transformer Type Isolation and Data Interface (Encapsulated)
Isolation Voltage 3500V
Application GENERAL PURPOSE
DC Resistance (DCR) 400mOhm
Inductance 1.6mH
Physical Dimension L22.7XB22.3XH13.6 (mm)
Approval Agency VDE
Number of Functions 1
Terminal Finish Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
JESD-609 Code e3
Size / Dimension 0.878Lx0.894W 22.30mmx22.70mm
Series ITNF
Published 2014
Packaging Bulk
Operating Temperature -25°C~100°C
Physical
Weight 0.35oz 9.97g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 23 Weeks
