DP241-5-12A22
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 12VA CHAS MOUNT
PDF
/
Inventory: 2446
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Height Seated (Max) 35.05mm
Length 71.37mm
Width 35.05mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Technical
VA Rating 12 VA
Secondary Winding(s) Single
Voltage - Secondary (Full Load) 12.6V
Center Tap Yes
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 12.6V
Power - Max 12VA
Max Output Current 1A
Voltage - Isolation 2500Vrms
Physical Dimension L71.37XB35.05XH41.4 (mm)
Approval Agency UL; CSA
Termination Style Solder, Quick Connect
Max Power Dissipation 12W
Power Rating 12W
Additional Feature HIGH ISOLATION
Type Laminated Core
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 71.37mm Lx41.40mm W
Series Chassis-Tran
Published 2009
Packaging Bulk
Physical
Weight 0.7lb 317.51g
Mounting Type Chassis Mount
Mount Chassis Mount
