160D10
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
Power Transformers LOW VOLTAGE RECT
PDF
/
Buying Options
Total Price: USD $8.43
Unit Price: USD $8.4304
≥1 USD $8.4304
≥10 USD $6.74256
Inventory: 1150
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 21.08mm
Height 21.082mm
Technical
VA Rating 1 VA
Secondary Winding(s) Single, Multiple Taps
Voltage - Secondary (Full Load) Parallel 5V Series 10V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Power - Max 1VA
Current - Output (Max) Parallel 180mA Series 90mA
Max Output Current 90mA
Voltage - Isolation 2000Vrms
Approval Agency UL; CSA
Termination Style PC Pin
Current Rating 90mA
Max Power Dissipation 1W
Power Rating 1W
HTS Code 8504.31.40.35
Additional Feature PCB MOUNTABLE
Min Operating Temperature 0°C
Max Operating Temperature 130°C
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 25.40mm Lx35.05mm W
Series 160
Published 2000
Physical
Weight 0.13lb 58.97g
Mounting Type Through Hole
Mount PCB, Through Hole
Supply Chain
Factory Lead Time 12 Weeks
