6444R-028
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Power Transformers
Description
XFRMR LAMINATED 5VA THRU HOLE
PDF
/
Inventory: 6517
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 36.58mm
Length 41.4mm
Height Seated (Max) 33.32mm
Technical
VA Rating 5 VA
Number of Secondary Winding 2
Output Voltage 2 14V
Voltage - Secondary (Full Load) Parallel 14V Series 28V
Center Tap No
Primary Winding(s) Dual
Voltage - Primary 115V 230V
Output Voltage 1 14V
Power - Max 5VA
Current - Output (Max) Parallel 360mA Series 180mA
Max Output Current 180mA
Voltage - Isolation 4000Vrms
Physical Dimension L41.40XB36.58XH35.05 (mm)
Operating Temperature (Max) 130°C
Approval Agency UL; CSA
Termination Style PC Pin
Max Power Dissipation 5W
Power Rating 5W
Terminal Finish Tin (Sn)
Type Laminated Core
ECCN Code EAR99
Termination PC Pin
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 41.28mm Lx33.32mm W
Series 6444R
Published 2011
Packaging Bulk
Physical
Weight 0.37lb 167.83g
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 13 Weeks
