B84111A0000B110
RoHS
/
Package /
Category Filters / Power Line Filter Modules
Description
Quick Connect SINGLE PHASE EMI FILTER UL; CSA; ENEC-10 TAB CONNECTORS ON FACE ENDS MOUNTING TABS ON FACE ENDS EMC/EMI Line Filter 10A 50/60Hz Hz 76.5mm 820muH
PDF
/
Buying Options
Total Price: USD $24.27
Unit Price: USD $24.2704
≥1 USD $24.2704
≥10 USD $23.48544
≥100 USD $22.702627
≥500 USD $21.919841
≥1000 USD $21.7459
Inventory: 79
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mounting Type PANEL MOUNT
Technical
Pbfree Code yes
Termination Quick Connect
Max Operating Temperature 85°C
Min Operating Temperature -25°C
Additional Feature TAB CONNECTORS ON FACE ENDS, MOUNTING TABS ON FACE ENDS
Capacitance 100nF
Voltage - Rated DC 250V
Depth 45mm
Current Rating 10A
Voltage - Rated AC 250V
Approval Agency UL; CSA; ENEC-10
Physical Dimension L50XB45XH28.6 (mm)
Operating Frequency 50/60Hz Hz
Inductance 820 μH
Max Voltage Rating (AC) 250V
Max Voltage Rating (DC) 250V
Filter Type SINGLE PHASE EMI FILTER
Current Rating (Max) 10A
Leakage Current (Max) 0.5mA
High Pot 2700 V
Dimensions
Height 38.1mm
Length 76.5mm
Width 63.5mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
