4303.0034
RoHS
RoHS compliant
RoHS compliantPackage Module
Category Connectors, Interconnects / Power Entry Connectors - Inlets, Outlets, Modules
Description
KEC ROHS3Compliant Straight GENERAL PURPOSE Power Entry Connector Receptacle, Male Blades - Module UL94V-0 13A 250V 0.098 2.50mm
PDF
/
Buying Options
Total Price: USD $6.14
Unit Price: USD $6.1424
≥1 USD $6.1424
≥10 USD $4.47744
≥100 USD $3.52352
≥500 USD $3.4474
Inventory: 62
Minimum: 1
-
+
Technical Details
Technical
Orientation Straight
Ingress Protection IP40
Approval Agency CCC, CSA, ENEC, UL
Mating Information MULTIPLE MATING PARTS AVAILABLE
Panel Cutout Dimensions Rectangular - 27.60mm x 50.00mm
Body/Shell Style SOCKET
Max Voltage Rating (AC) 250V
Connector Style IEC 320-C14
Current 13A
Voltage - UL 125VAC
Voltage - IEC 250VAC
Filter Type Unfiltered - Commercial
Current - IEC 10A
Accomodates a Fuse Yes (Fuse Not Included)
Fuse Yes
Fuse Holder, Drawer Drawer Sold Separate
Total Number of Contacts 3
Option GENERAL PURPOSE
IEC Conformance YES
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 125V
Gender Male
Number of Positions 3
Connector Type Receptacle, Male Blades - Module
Termination Quick Connect - 0.189 (4.8mm)
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Series KEC
Packaging Bulk
Dimensions
Panel Thickness 0.098 2.50mm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
Physical
Weight 24.700004g
Shell Material POLYETHYLENE
Package / Case Module
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Supply Chain
Factory Lead Time 13 Weeks
