IGCM15F60GAXKMA1
RoHS
RoHS compliant
RoHS compliantPackage 24-PowerDIP Module (1.028, 26.10mm)
Category Discrete Semiconductor Products / Power Driver Modules
Description
Motor / Motion / Ignition Controllers & Drivers MINI DUAL-IN-LINE 15A/600V W/NTC 24PIN
PDF
/
Buying Options
Total Price: USD $9.86
Unit Price: USD $9.8648
≥1 USD $9.8648
≥10 USD $8.451775
≥100 USD $7.043379
≥500 USD $6.214701
≥1000 USD $5.593236
Inventory: 709
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 20 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 24-PowerDIP Module (1.028, 26.10mm)
Number of Pins 24
Technical
Published 2015
Series CIPOS?
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Type IGBT
Max Operating Temperature 150°C
Min Operating Temperature -40°C
HTS Code 8542.39.00.01
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 16V
Current Rating 15A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Voltage - Isolation 2000Vrms
Halogen Free Halogen Free
Output Current 15A
Configuration 3 Phase
Supply Voltage-Min (Vsup) 14V
Temperature Grade INDUSTRIAL
Supply Voltage-Max (Vsup) 18.5V
Output Voltage 600V
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 21mm
Length 36mm
Height Seated (Max) 5.6mm
