ST4ETA102
RoHS
/
Package /
Category / Potentiometers, Variable Resistors
Description
Res Cermet Trimmer 1K Ohm 20% 1/4W 1(Elec)/1(Mech)Turn 2.3mm (5 X 5.2 X 2.3mm) J-Hook SMD Embossed T/R
PDF
/
Buying Options
Total Price: USD $0.69
Unit Price: USD $0.6916
≥1 USD $0.6916
≥10 USD $0.5681
≥100 USD $0.55005
≥500 USD $0.532
≥1000 USD $0.5149
Inventory: 4006
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 4.5mm
Length 5.2mm
Height 2.3mm
Technical
Rotation Angle 3600 deg
Actuator Orientation VERTICAL
Number of Turns 1
Rated Temperature 70°C
Size Code 2020
Working Voltage 15.8V
Operating Temperature (Min) -55°C
Actuator Type SCREW
Operating Temperature (Max) 125°C
Rated Power Dissipation (P) 0.25W
Resistor Type TRIMMER
Construction Sealed
Technology CERMET
Packing Method TR, EMBOSSED, 7 INCH
Power Rating 250mW
Subcategory Variable Resistors
HTS Code 8533.40.80.50
Color Black
Terminal Finish Tin/Copper (Sn/Cu)
Resistance 1kOhm
Temperature Coefficient -100100 ppm/°C
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 3
Pbfree Code yes
JESD-609 Code e2
Tolerance 20%
Series ST-4
Physical
Weight 120mg
Mounting Feature SURFACE MOUNT
Terminal Shape J BEND
Surface Mount YES
