UA78M09CKVURG3
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
UA78M09 Tape & Reel (TR) Surface Mount Over Current Over Temperature Short Circuit voltage regulator linear 2V 2.52mm 500mA 0C~125C
PDF
/
Buying Options
Total Price: USD $4.49
Unit Price: USD $4.4935
≥1 USD $4.4935
≥10 USD $3.68695
≥100 USD $3.572
≥500 USD $3.4561
≥1000 USD $3.34115
Inventory: 2501
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 2.3mm
Width 6.6mm
Length 6.1mm
Height 2.52mm
Technical
Voltage Tolerance-Max 5.5%
Power Supply Rejection Ratio (PSRR) 80dB
Dropout Voltage1-Nom 2V
Dropout Voltage 2V
PSRR 80dB (120Hz)
Voltage Dropout (Max) 2V @ 350mA
Protection Features Over Current, Over Temperature, Short Circuit
Min Input Voltage 11.5V
Number of Regulators 1
Output Voltage 1 9V
Quiescent Current 4.6mA
Output Configuration Positive
Max Output Current 500mA
Output Type Fixed
Output Voltage 9V
Voltage - Input (Max) 26V
Number of Outputs 1
JESD-30 Code R-PSSO-G2
Pin Count 2
Base Part Number UA78M09
Terminal Pitch 2.29mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position SINGLE
Technology BIPOLAR
Packing Method TR
Subcategory Other Regulators
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C
Physical
Weight 328.797769mg
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
