TPS73512QDRBRQ1
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
TPS73512 Tape & Reel (TR) Surface Mount Over Current Over Temperature Reverse Polarity Under Voltage Lockout (UVLO) voltage regulator linear 280mV 1mm 500mA -40C~125C
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.26248
≥1 USD $1.26248
≥10 USD $1.19102
≥100 USD $1.1236
≥500 USD $1.06
≥1000 USD $1
≥3000 USD $0.9434
Inventory: 6027
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VDFN Exposed Pad
Number of Pins 8
Weight 75.891673mg
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series Automotive, AEC-Q100
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Packing Method TR
Technology BICMOS
Terminal Position DUAL
Terminal Form NO LEAD
Number of Functions 1
Terminal Pitch 0.65mm
Base Part Number TPS73512
Number of Outputs 1
Voltage - Input (Max) 6.5V
Output Voltage 1.2V
Output Type Fixed
Output Configuration Positive
Current - Output 500mA
Quiescent Current 45μA
Control Features Enable
Output Voltage 1 1.2V
Number of Regulators 1
Min Input Voltage 2.7V
Protection Features Over Current, Over Temperature, Reverse Polarity, Under Voltage Lockout (UVLO)
Current - Quiescent (Iq) 65μA
Voltage Dropout (Max) 0.5V @ 500mA
PSRR 60dB ~ 21dB (100Hz ~ 100kHz)
Dropout Voltage 280mV
Dropout Voltage1-Nom 0.28V
Power Supply Rejection Ratio (PSRR) 21dB
Voltage Tolerance-Max 3%
Min Current Limit 800mA
Input Voltage Absolute-Max 7V
Dimensions
Height 1mm
Length 3mm
Width 3mm
Thickness 880μm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
