TPS71334DRCTG4
RoHS
/
Package QFN
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
FIXED/ADJUSTABLE QFN RoHS Compliant Nickel/Palladium/Gold (Ni/Pd/Au) voltage regulator linear 125mV 900mum 200mA 1.92W
PDF
/
Buying Options
Total Price: USD $0.98
Unit Price: USD $0.979573
≥1 USD $0.979573
≥10 USD $0.924131
≥100 USD $0.871818
≥500 USD $0.822478
≥1000 USD $0.77592
Inventory: 1187
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height 900μm
Technical
Voltage Reference 1.225V
Adjustability FIXED/ADJUSTABLE
Output Voltage Accuracy 1.5 %
Min Current Limit 400mA
Voltage Tolerance-Max 3%
Min Output Voltage 3.3V
Dropout Voltage1-Nom 0.125V
Dropout Voltage 125mV
Max Input Voltage 5.5V
Current - Input Bias 190μA
Min Input Voltage 2.7V
Output Voltage 1 3.3V
Voltage - Output 5.5V
Max Output Voltage 3.3V
Accuracy 1.5 %
Quiescent Current 300μA
Current - Output 250mA
Power Dissipation 1.92W
Power Dissipation-Max 1.92W
Polarity Positive
Max Output Current 200mA
Output Type Adjustable, Fixed
Number of Outputs 2
Pin Count 10
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Power Rating 1.92W
Subcategory Other Regulators
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 10
Moisture Sensitivity Level (MSL) 2
JESD-609 Code e4
Physical
Number of Pins 10
Surface Mount YES
Package / Case QFN
