TPS60401DBVRG4

Texas Instruments
RoHS
RoHS RoHS compliant
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Regulators
Description Inverting ROHS3Compliant Fixed Positive or Negative DC to DC switching regulator -40C~125C TJ 20kHz 60mA 1.6mm
PDF
/
Buying Options
Total Price: USD $0.94
Unit Price: USD $0.9405
≥1 USD $0.9405
≥10 USD $0.7714
≥100 USD $0.74765
≥500 USD $0.72295
≥1000 USD $0.6992
Inventory: 47694
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Thickness 1.2mm
Width 1.6mm
Length 2.9mm
Height 1.45mm

Technical

Switcher Configuration DOUBLER INVERTER
Min Output Voltage -1.6V
Synchronous Rectifier No
Frequency - Switching 20kHz
Logic Function Inverting
Topology Charge Pump
Voltage - Output (Min/Fixed) -Vin 2Vin Vin/2
Max Output Voltage -5.25V
Quiescent Current 65μA
Output Configuration Positive or Negative
Nominal Supply Current 70μA
Analog IC - Other Type SWITCHED CAPACITOR CONVERTER
Min Supply Voltage 1.8V
Max Supply Voltage 5.25V
Input Voltage-Nom 5V
Max Output Current 60mA
Output Type Fixed
Output Voltage -5.25V
Number of Outputs 1
Function Ratiometric
Base Part Number TPS60401
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ

Physical

Weight 13.012431mg
Number of Pins 5
Surface Mount YES
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
