LM5041AMTC
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
LM5041 Half-Bridge Push-Pull Tube e0 DC to DC switching controller 20ns 100mA 900mum 5V
PDF
/
Buying Options
Total Price: USD $6.71
Unit Price: USD $6.7127
≥1 USD $6.7127
≥10 USD $5.5081
≥100 USD $5.3352
≥500 USD $5.16325
≥1000 USD $4.9913
Inventory: 1616
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Switching Regulator or Controllers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Frequency 600kHz
Base Part Number LM5041
Function Step-Up/Step-Down
Number of Outputs 1
Output Voltage 5V
Output Type Transistor Driver
Max Output Current 5A
Input Voltage-Nom 48V
Analog IC - Other Type SWITCHING CONTROLLER
Output Configuration Positive
Output Current 100mA
Voltage - Supply (Vcc/Vdd) 15V~90V
Output Power 500W
Control Features Dead Time Control, Frequency Control, Soft Start
Topology Half-Bridge, Push-Pull
Control Mode VOLTAGE-MODE
Frequency - Switching 200kHz 600kHz
Max Input Voltage 90V
Control Technique PULSE WIDTH MODULATION
Rise Time 20ns
Synchronous Rectifier Yes
Fall Time (Typ) 20 ns
Nominal Input Voltage 48V
Max Duty Cycle 50 %
Duty Cycle 50 %
Dimensions
Height 900μm
Length 5mm
Width 4.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
