MAX1847EEE+T
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - DC DC Switching Controllers
Description
MAX1847 Flyback Tape & Reel (TR) e3 DC to DC switching controller 4.89mm -2V 100kHz~500kHz -40C~85C TA
PDF
/
Buying Options
Total Price: USD $6.51
Unit Price: USD $6.512
≥1 USD $6.512
≥10 USD $5.88544
≥100 USD $5.611936
≥500 USD $4.872736
≥1000 USD $4.653757
≥3000 USD $4.243131
Inventory: 1373
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.89mm
Technical
Clock Sync Yes
Duty Cycle (Max) 96%
Max Frequency 345kHz
Switcher Configuration SINGLE
Synchronous Rectifier No
Control Technique PULSE WIDTH MODULATION
Max Input Voltage 16.5V
Frequency - Switching 100kHz~500kHz
Control Mode CURRENT-MODE
Min Input Voltage 3V
Topology Flyback
Control Features Enable, Frequency Control
Voltage - Supply (Vcc/Vdd) 3V~16.5V
Output Configuration Negative
Analog IC - Other Type SWITCHING CONTROLLER
Input Voltage-Nom 12V
Operating Supply Voltage 16.5V
Output Type Transistor Driver
Output Voltage -2V
Efficiency 90 %
Number of Outputs 1
Function Step-Up/Step-Down
Base Part Number MAX1847
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.635mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Subcategory Switching Regulator or Controllers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 16
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
Alternative Model
