LM4040AIM3-2.5
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
Surface Mount GULL WING Non-RoHS Compliant DUAL Shunt Voltage Reference IC 2mm ±0.1% 1.1mm 100ppm/C
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.73602
≥1 USD $0.73602
≥10 USD $0.69436
≥100 USD $0.65506
≥500 USD $0.61798
≥1000 USD $0.583
≥3000 USD $0.55
Inventory: 13208
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 1.25mm
Length 2mm
Height Seated (Max) 1.1mm
Technical
Noise - 10Hz to 10kHz 35μVrms
Current - Cathode 65μA
Temp Coef of Voltage-Max 100 ppm/°C
Output Voltage-Min 2.481V
Output Voltage-Max 2.519V
Reference Type Shunt
Voltage - Output (Min/Fixed) 2.5V
Current - Output 15mA
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Trim/Adjustable Output NO
Output Type Fixed
Output Voltage 2.5V
Number of Outputs 1
JESD-30 Code R-PDSO-G3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 20
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Technology BICMOS
Terminal Finish TIN LEAD
Temperature Coefficient 100ppm/°C
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Tolerance ±0.1%
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
