MIC2075-1BM-TR
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Power Distribution Switches, Load Drivers
Description
Non-RoHS Compliant Non-Inverting Discontinued N-Channel General Purpose Power Switch/Driver -40C~85C TA 90mOhm 500mA 2.7V~5.5V
PDF
/
Buying Options
Total Price: USD $0.4
Unit Price: USD $0.4028
≥1 USD $0.4028
≥10 USD $0.3306
≥100 USD $0.32015
≥500 USD $0.31065
≥1000 USD $0.3002
Inventory: 1779
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Rds On (Typ) 90mOhm
Fault Protection Current Limiting (Fixed), Over Temperature, UVLO
Voltage - Load 2.7V~5.5V
Ratio - Input:Output 1:1
Switch Type General Purpose
Input Type Non-Inverting
Voltage - Supply (Vcc/Vdd) Not Required
Output Configuration High Side
Current - Output (Max) 500mA
Interface On/Off
Output Type N-Channel
Number of Outputs 1
Base Part Number MIC2075
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Feature Slew Rate Controlled, Status Flag
Series MM8?
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Supplier Device Package 8-SOIC
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
