LT3756EMSE#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-TFSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description
Tube LT3756 Flyback SEPIC Step-Down (Buck) Step-Up (Boost) Analog PWM led driver 4.039mm 24V 100kHz~1MHz -40C~125C TJ
PDF
/
Buying Options
Total Price: USD $8.4
Unit Price: USD $8.3952
≥1 USD $8.3952
≥10 USD $7.58648
≥100 USD $7.2336
≥500 USD $6.280824
≥1000 USD $5.998511
≥3000 USD $5.469235
Inventory: 637
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 16-TFSOP (0.118, 3.00mm Width) Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~125°C TJ
Packaging Tube
Published 2005
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type DC DC Controller
Terminal Finish Matte Tin (Sn)
Subcategory Display Drivers
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 24V
Terminal Pitch 0.5mm
Frequency 100kHz~1MHz
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LT3756
Pin Count 16
Number of Outputs 1
Power Supplies 24V
Topology Flyback, SEPIC, Step-Down (Buck), Step-Up (Boost)
Internal Switch(s) No
Dimming Analog, PWM
Number of Segments 18
Voltage - Supply (Max) 100V
Voltage - Supply (Min) 6V
Multiplexed Display Capability NO
Dimensions
Length 4.039mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
