RoHS
/
Package SMD/SMT
Category Integrated Circuits (ICs) / PMIC - LED Drivers
Description IC LED DRIVER LINEAR SCT595-5
PDF
/
Inventory: 5804
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case SMD/SMT
Surface Mount YES
Number of Pins 5

Technical

Moisture Sensitivity Level (MSL) 1
Number of Terminations 5
ECCN Code EAR99
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Subcategory Display Drivers
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 13.5V
Pin Count 5
Number of Outputs 1
Max Supply Voltage 45V
Min Supply Voltage 3V
Halogen Free Not Halogen Free
Interface IC Type LED DISPLAY DRIVER
Low Level Output Current 1.5mA
Number of Segments 3
Multiplexed Display Capability NO
Data Input Mode SERIAL

Dimensions

Length 2.9mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
