LV51134T-TLM-E
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Battery Management
Description
Lead Free RoHS Compliant Battery Protection GULL WING IC Battery Protection 170mW -30C~80C TA 0.635mm 10V
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.6248
≥1 USD $0.6248
Inventory: 81858
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Number of Cells 2
Battery Chemistry Lithium-Ion
Fault Protection Over Current, Short Circuit
Supply Current-Max (Isup) 0.013mA
Operating Supply Current 6μA
Analog IC - Other Type POWER SUPPLY SUPPORT CIRCUIT
Min Supply Voltage 1.5V
Max Supply Voltage 10V
Output Voltage 300mV
Function Battery Protection
Base Part Number LV51134
Terminal Pitch 0.635mm
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Max Power Dissipation 170mW
Subcategory Power Management Circuits
Terminal Finish Tin/Bismuth (Sn/Bi)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e6
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -30°C~80°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
