DSC1001AI1-024.5450
RoHS
RoHS compliant
RoHS compliantPackage 4-VDFN Exposed Pad
Category Crystals, Oscillators, Resonators / Oscillators
Description
MEMS RoHS Compliant Standby (Power Down) Active crystal oscillator 55/45% -40C~85C 2ns ±50ppm
PDF
/
Inventory: 4928
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q100
RoHS Status RoHS Compliant
Dimensions
Height Seated (Max) 0.035 0.90mm
Technical
Absolute Pull Range (APR) ±50ppm
Current - Supply (Disable) (Max) 15μA
Symmetry-Max 55/45%
Fall Time-Max 2ns
Rise Time-Max 2ns
Operating Frequency 24.545MHz
Physical Dimension 7.0mm x 5.0mm x 0.85mm
Current - Supply (Max) 8mA
Base Resonator MEMS
Function Standby (Power Down)
Output CMOS
Frequency 24.545MHz
Reach Compliance Code compliant
Supply Voltage 3.3V
Voltage - Supply 1.8V~3.3V
Terminal Finish Matte Tin (Sn)
Type XO (Standard)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Size / Dimension 0.276Lx0.197W 7.00mmx5.00mm
Series DSC1001
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 4-VDFN Exposed Pad
Mounting Type Surface Mount
