EP1300ETTS-20.000M

Ecliptek
RoHS
/
Package DIP
Category Crystals, Oscillators, Resonators / Oscillators
Description RoHS Compliant Metal Matte Tin (Sn) - with Nickel (Ni) barrier Radial Oscillator 30pF 85C 20.8mm x 13.2mm x 5.08mm 0.01%
PDF
/
Inventory: 5638
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Package / Case DIP
Surface Mount NO
Mounting Feature THROUGH HOLE MOUNT
Number of Pins 4
Material Metal

Technical

JESD-609 Code e3
Pbfree Code yes
Termination Radial
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature TRI-STATE; ENABLE/DISABLE FUNCTION
Supply Voltage 3.3V
Frequency 20MHz
Frequency Stability 100 ppm
Physical Dimension 20.8mm x 13.2mm x 5.08mm
Operating Frequency 20MHz
Operating Supply Voltage 3.3V
Supply Voltage-Max (Vsup) 3.6V
Oscillator Type HCMOS/TTL
Load Capacitance 30pF
Frequency Tolerance 0.01%

Compliance

RoHS Status RoHS Compliant
