CA50C1007PMT
RoHS
RoHS compliant
RoHS compliantPackage 4-SMD, No Lead
Category Crystals, Oscillators, Resonators / Oscillators
Description
XTAL OSC XO 10.0MHZ 1.8V SMD
PDF
/
Inventory: 7450
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.051 1.30mm
Technical
Current - Supply (Disable) (Max) 10μA
Symmetry-Max 55/45%
Fall Time-Max 5ns
Rise Time-Max 5ns
Operating Frequency 10MHz
Physical Dimension 5.0mm x 3.2mm x 1.3mm
Current - Supply (Max) 25mA
Base Resonator Crystal
Function Enable/Disable
Output HCMOS, TTL
Frequency Stability ±150ppm
Frequency 10MHz
Supply Voltage 1.8V
Voltage - Supply 1.8V
Terminal Finish Gold (Au) - with Nickel (Ni) barrier
Type XO (Standard)
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e4
Size / Dimension 0.197Lx0.126W 5.00mmx3.20mm
Series CA50
Packaging Tape & Reel (TR)
Operating Temperature -55°C~105°C
Physical
Surface Mount YES
Package / Case 4-SMD, No Lead
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
