PS9303L2-V-E3-AX
RoHS
RoHS compliant
RoHS compliantPackage 6-SOIC (0.268, 6.80mm Width)
Category Isolators / Optoisolators - Logic Output
Description
6-SOIC (0.268 6.80mm Width) 1 1/0 DC Logic Output Optoisolator 15kV/mus 5000Vrms 1Mbps 20mA
PDF
/
Buying Options
Total Price: USD $3.88
Unit Price: USD $3.8808
≥1 USD $3.8808
≥10 USD $2.74384
≥100 USD $2.247256
≥500 USD $1.894482
≥1000 USD $1.737692
Inventory: 2010
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Inputs - Side 1/Side 2 1/0
Common Mode Transient Immunity (Min) 15kV/μs
Propagation Delay tpLH / tpHL (Max) 500ns, 550ns
Current - DC Forward (If) (Max) 20mA
Rise / Fall Time (Typ) 120ns 90ns
Output Current per Channel 25mA
Data Rate 1Mbps
Input Type DC
Propagation Delay 550 ns
Voltage - Forward (Vf) (Typ) 1.6V
Number of Channels 1
Output Type Push-Pull, Totem Pole
Voltage - Isolation 5000Vrms
Voltage - Supply 4.5V~20V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Series NEPOC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~100°C
Physical
Package / Case 6-SOIC (0.268, 6.80mm Width)
Mounting Type Surface Mount
Mount Surface Mount
