HCPL-0466-560E
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Isolators / Optoisolators - Logic Output
Description
OPTOISO 3.75KV OPN COLLECTOR 8SO
PDF
/
Buying Options
Total Price: USD $1.62
Unit Price: USD $1.61975
≥1 USD $1.61975
≥10 USD $1.32905
≥100 USD $1.28725
≥500 USD $1.24545
≥1000 USD $1.2046
Inventory: 14703
Minimum: 1
-
+
Technical Details
Technical
Number of Elements 1
Configuration SINGLE
Number of Channels 1
Power Dissipation 145mW
Output Current 15mA
Voltage - Forward (Vf) (Typ) 1.5V
Propagation Delay 650 ns
Input Type DC
Turn On Delay Time 650 ns
Optoelectronic Device Type LOGIC IC OUTPUT OPTOCOUPLER
Forward Current 25mA
Direction Unidirectional
Output Current per Channel 15mA
Reverse Breakdown Voltage 5V
Propagation Delay tpLH / tpHL (Max) 550ns, 400ns
Common Mode Transient Immunity (Min) 15kV/μs
Inputs - Side 1/Side 2 1/0
Current Transfer Ratio 90 %
Max Output Current 15mA
Output Type Open Collector, Schottky Clamped
Voltage - Isolation 3750Vrms
Voltage - Supply 4.5V~30V
Max Power Dissipation 145mW
Additional Feature UL RECOGNIZED, VDE APPROVED
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2013
Packaging Tape & Reel (TR)
Operating Temperature -40°C~100°C
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 17 Weeks
