A3230LUA
RoHS
/
Package 3-SSIP
Category Sensors, Transducers / Magnetic Sensors - Switches (Solid State)
Description
MAGNETIC SWITCH BIPOLAR 3SIP
PDF
/
Inventory: 6972
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Through Hole
Package / Case 3-SSIP
Surface Mount NO
Technical
Operating Temperature -40°C~150°C TA
Packaging Bulk
Published 2013
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature SHORT CIRCUIT PROTECTION, REVERSE BATTERY PROTECTION
HTS Code 8542.39.00.01
Technology Hall Effect
Voltage - Supply 3.6V~24V
Function Bipolar Switch
Current - Supply (Max) 3.5mA
Body Length or Diameter 4.105mm
Body Breadth 1.52 mm
Output Type Open Drain
Max Output Current 60mA
Termination Type SOLDER
Operating Supply Current 3.5mA
Polarization South Pole
Test Condition -40°C ~ 150°C
Sensing Range 2.5mT Trip, -2.5mT Release
Hysteresis 1.5 mT
Output Range 30-60mA
Magnetic Field Range-Min -2.5 mT
Magnetic Field Range-Max 2.5 mT
Dimensions
Body Height 5.26mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
