TXB0101DBVRG4
RoHS
/
Package SOT-23
Category Integrated Circuits (ICs) / Logic - Translators, Level Shifters
Description
e4 Nickel/Palladium/Gold (Ni/Pd/Au) Tape & Reel (TR) Lead Free level shifter translator 31ns 1.5V 6.492041mg -20muA
PDF
/
Inventory: 2424
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 2.9mm
Technical
Supply Voltage1-Nom 1.8V
Low Level Output Current 20μA
High Level Output Current -20μA
Interface IC Type INTERFACE CIRCUIT
Data Rate 100 Mbps
Logic Function Translator
Turn On Delay Time 7.4 ns
Propagation Delay 31 ns
Number of Bits 1
Min Supply Voltage 1.2V
Max Supply Voltage 5.5V
Temperature Grade INDUSTRIAL
Pin Count 6
Terminal Pitch 0.95mm
Supply Voltage 1.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Interface ICs
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Tape & Reel (TR)
Physical
Weight 6.492041mg
Number of Pins 6
Package / Case SOT-23
Mount Surface Mount
