SN10KHT5543NT
RoHS
RoHS compliant
RoHS compliantPackage 24-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Translators, Level Shifters
Description
Unidirectional TRUE ROHS3Compliant DUAL Mixed Signal Translator 0C~75C TA 2.54mm 5V 3.3ns
PDF
/
Inventory: 4126
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.62mm
Technical
Delay-Max 3.3 ns
Output Latch or Register NONE
Channels per Circuit 8
Input Signal TTL
Translator Type Mixed Signal
Output Signal ECL
Negative Supply Voltage-Nom -5.2V
Channel Type Unidirectional
Output Polarity TRUE
Output Characteristics OPEN-EMITTER
Number of Bits 1
Number of Circuits 1
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Output Type Non-Inverted
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T24
Pin Count 24
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 2.54mm
Supply Voltage 5V
Number of Functions 8
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position DUAL
Technology BIPOLAR
Terminal Finish NICKEL PALLADIUM GOLD
Number of Terminations 24
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~75°C TA
Physical
Surface Mount NO
Package / Case 24-DIP (0.300, 7.62mm)
Mounting Type Through Hole
