SN74F283NSRG4
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC, 4BIT BINARY FULL ADDER, 6.6NS SOIC16
PDF
/
Inventory: 1656
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 5.3mm
Height Seated (Max) 2mm
Technical
Low Level Output Current 20mA
High Level Output Current -1mA
Output Polarity TRUE
Logic Type Binary Full Adder with Fast Carry
Logic Function Binary Full Adder
Family F/FAST
Turn On Delay Time 10.5 ns
Propagation Delay 9.5 ns
Number of Bits 4
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Number of Channels 1
Power Supplies 5V
Operating Supply Voltage 5V
Qualification Status Not Qualified
Pin Count 16
Base Part Number 74F283
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 4.5V~5.5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology TTL
Subcategory Arithmetic Circuits
Additional Feature INTERNAL FULL-CARRY LOOK-AHEAD
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
Series 74F
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C
Physical
Weight 200.686274mg
Number of Pins 16
Package / Case 16-SOIC (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
