MC10EP16VAMNR4G
RoHS
/
Package 8-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC RCVR/DRVR 3.3/5 DIFF ECL 8DFN
PDF
/
Buying Options
Total Price: USD $8.83
Unit Price: USD $8.832712
≥1 USD $8.832712
≥10 USD $8.332749
≥100 USD $7.861082
≥500 USD $7.416116
≥1000 USD $6.996336
Inventory: 1271
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 2mm
Length 2mm
Technical
Transmit Delay-Max 0.34 ns
Negative Supply Voltage-Nom -5.2V
Receive Delay-Max 0.34 ns
Interface Standard GENERAL PURPOSE
Interface IC Type LINE TRANSCEIVER
Differential Output YES
Logic Type Differential Receiver/Driver
Halogen Free Halogen Free
Logic Function Receiver
Number of Bits 1
Nominal Supply Current 42mA
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Power Supplies -5.2V
Qualification Status Not Qualified
JESD-30 Code S-PDSO-N8
Pin Count 8
Base Part Number 10EP16
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.5mm
Supply Voltage 3V~5.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Technology ECL
Additional Feature CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE
Terminal Finish Nickel/Gold/Palladium (Ni/Au/Pd)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 10EP
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 8-VFDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
