SN74LV373ATPWT
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Discontinued Contains Lead D-Type Transparent Latch 50pF 10MHz -40C~85C 76.997305mg
PDF
/
Buying Options
Total Price: USD $1.6
Unit Price: USD $1.601866
≥1 USD $1.601866
≥10 USD $1.511198
≥100 USD $1.425655
≥500 USD $1.34496
≥1000 USD $1.268825
Inventory: 4272
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.4mm
Length 6.5mm
Technical
Independent Circuits 1
Number of Input Lines 8
Logic Type D-Type Transparent Latch
Current - Output High, Low 16mA 16mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family LV/LV-A/LVX/H
Turn On Delay Time 1 ns
Propagation Delay 15 ns
Number of Bits 8
Output Current 16mA
Number of Ports 2
Load Capacitance 50pF
Power Supplies 3.3V
Polarity Non-Inverting
Circuit 8:8
Operating Supply Voltage 5V
Output Type Tri-State
Pin Count 20
Base Part Number 74LV373
Frequency 10MHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~5.5V
Technology CMOS
Packing Method TR
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Termination SMD/SMT
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Pbfree Code yes
JESD-609 Code e4
Series 74LV
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Weight 76.997305mg
Number of Pins 20
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
