CD4002BPW
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NOR CD4002 e4 4000B logic gate circuit 90ns @ 15V 50pF 1.2mm 3.4mA 3.4mA 3.5V-11V
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.1528
≥1 USD $1.1528
≥10 USD $1.03048
≥100 USD $0.803343
≥500 USD $0.751001
≥1000 USD $0.66367
Inventory: 798
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1mm
Width 4.4mm
Length 5mm
Height 1.2mm
Technical
Current - Quiescent (Max) 1μA
Power Supply Current-Max (ICC) 0.03mA
Logic Level - High 3.5V ~ 11V
Logic Level - Low 1.5V ~ 4V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 90ns @ 15V, 50pF
Max I(ol) 0.0068 A
Logic Type NOR Gate
Current - Output High, Low 3.4mA 3.4mA
Number of Inputs 4
Logic Function NOR
Turn On Delay Time 120 ns
Quiescent Current 5μA
Propagation Delay 90 ns
Output Current 6.8mA
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Number of Elements 2
Max Output Current 6.8mA
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number CD4002
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Subcategory Gates
Termination SMD/SMT
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 4000B
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Weight 57.209338mg
Number of Pins 14
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
