SN74LVC2G79YEPR
RoHS
RoHS compliant
RoHS compliantPackage 8-XFBGA, DSBGA
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Contains Lead Not Qualified Standard D-Type Flip Flop -40C~85C TA 5muA 3.5pF 1.65V~5.5V
PDF
/
Buying Options
Total Price: USD $0.22
Unit Price: USD $0.22
≥1 USD $0.22
Inventory: 3028
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Dimensions
Width 0.9mm
Height Seated (Max) 0.5mm
Technical
Clock Edge Trigger Type Positive Edge
Propagation Delay (tpd) 9.9 ns
Input Capacitance 3.5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 4.5ns @ 5V, 50pF
Number of Bits per Element 1
Current - Output High, Low 32mA 32mA
Current - Quiescent (Iq) 5μA
Family LVC/LCX/Z
Turn On Delay Time 1.1 ns
Clock Frequency 160MHz
Load Capacitance 50pF
Power Supplies 3.3V
Supply Voltage-Max (Vsup) 5.5V
Polarity Non-Inverting
Number of Elements 2
Output Type Non-Inverted
Qualification Status Not Qualified
Function Standard
JESD-30 Code R-XBGA-B8
Base Part Number 74LVC2G79
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 0.5mm
Supply Voltage 1.8V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 1.65V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Type D-Type
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74LVC
Packaging Cut Tape (CT)
Operating Temperature -40°C~85°C TA
Physical
Package / Case 8-XFBGA, DSBGA
Mounting Type Surface Mount
Mount Surface Mount
