SN74LVC2G74YZPR
RoHS
RoHS compliant
RoHS compliantPackage 8-XFBGA, DSBGA
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Cut Tape (CT) 74LVC2G74 e1 74LVC flip flop 1.25mm 5.4ns @ 5V 50pF 140MHz 5.9ns
PDF
/
Buying Options
Total Price: USD $0.79
Unit Price: USD $0.792
≥1 USD $0.792
≥10 USD $0.69784
≥100 USD $0.655776
≥500 USD $0.535216
≥1000 USD $0.497094
≥3000 USD $0.423069
Inventory: 1487
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Plating Copper, Silver, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-XFBGA, DSBGA
Number of Pins 8
Weight 2.296311mg
Technical
Operating Temperature -40°C~85°C TA
Packaging Cut Tape (CT)
Series 74LVC
JESD-609 Code e1
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Type D-Type
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Subcategory FF/Latches
Packing Method TR
Technology CMOS
Voltage - Supply 1.65V~5.5V
Terminal Position BOTTOM
Terminal Form BALL
Peak Reflow Temperature (Cel) 260
Supply Voltage 1.8V
Terminal Pitch 0.5mm
Base Part Number 74LVC2G74
Function Set(Preset) and Reset
Output Type Differential
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3.3V
Number of Circuits 1
Number of Bits 1
Clock Frequency 140MHz
Propagation Delay 14.4 ns
Quiescent Current 10μA
Turn On Delay Time 4.1 ns
Family LVC/LCX/Z
Logic Function AND, D-Type
Output Characteristics 3-STATE
Current - Output High, Low 32mA 32mA
Number of Gates 2
Max Propagation Delay @ V, Max CL 5.4ns @ 5V, 50pF
Prop. Delay@Nom-Sup 5.9 ns
Trigger Type Positive Edge
Input Capacitance 5pF
Clock Edge Trigger Type Positive Edge
Dimensions
Height 500μm
Length 1.25mm
Width 2.25mm
Thickness 310μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
