74LVT374MTCX
RoHS
RoHS compliant
RoHS compliantPackage 20-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) e3 74LVT MATTE TIN flip flop 6.5mm 2.7V 4.9ns @ 3.3V 50pF 160MHz
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2112
≥1 USD $0.2112
Inventory: 1595
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 20-TSSOP (0.173, 4.40mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series 74LVT
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
Type D-Type
Terminal Finish MATTE TIN
Technology BICMOS
Voltage - Supply 2.7V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Terminal Pitch 0.65mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G20
Function Standard
Output Type Tri-State, Non-Inverted
Number of Elements 1
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.7V
Number of Ports 2
Clock Frequency 160MHz
Family LVT
Current - Quiescent (Iq) 190μA
Output Characteristics 3-STATE
Current - Output High, Low 32mA 64mA
Output Polarity TRUE
Number of Bits per Element 8
Max Propagation Delay @ V, Max CL 4.9ns @ 3.3V, 50pF
Trigger Type Positive Edge
Input Capacitance 3pF
Propagation Delay (tpd) 5.2 ns
Dimensions
Length 6.5mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
