MC14027BD
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Contains Lead Not Qualified Set(Preset) and Reset JK Type Flip Flop -55C~125C TA 4muA 5pF 3V~18V
PDF
/
Inventory: 8877
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Technical
Clock Edge Trigger Type Positive Edge
fmax-Min 6.5 MHz
Number of Input Lines 2
Input Capacitance 5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 100ns @ 15V, 50pF
Number of Bits per Element 1
Current - Output High, Low 8.8mA 8.8mA
Current - Quiescent (Iq) 4μA
Logic Function AND, Flip-Flop
Turn On Delay Time 50 ns
Propagation Delay 350 ns
Clock Frequency 13MHz
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 3V
Polarity Non-Inverting
Output Type Differential
Qualification Status Not Qualified
Function Set(Preset) and Reset
Base Part Number 4027
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code not_compliant
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Packing Method RAIL
Subcategory FF/Latches
Terminal Finish Tin/Lead (Sn/Pb)
Type JK Type
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Series 4000B
Published 2009
Packaging Tube
Operating Temperature -55°C~125°C TA
Physical
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
