MC100EL51D
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Contains Lead Reset D-Type ECL Flip Flop -40C~85C TA 29mA -4.2V~-5.7V 0.62ns
PDF
/
Buying Options
Total Price: USD $5.35
Unit Price: USD $5.35325
≥1 USD $5.35325
≥10 USD $4.3928
≥100 USD $4.256
≥500 USD $4.11825
≥1000 USD $3.98145
Inventory: 7093
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2008
Series 100EL
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type D-Type
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature NECL MODE: VCC = 0V WITH VEE = -4.2V TO -5.7V
Subcategory FF/Latches
Packing Method RAIL
Technology ECL
Voltage - Supply -4.2V~-5.7V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 100EL51
Function Reset
Output Type Differential
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.7V
Power Supplies -4.5V
Supply Voltage-Min (Vsup) 4.2V
Number of Circuits 1
Number of Bits 1
Clock Frequency 2.8GHz
Propagation Delay 565 ps
Turn On Delay Time 475 ps
Logic Function Flip-Flop
Current - Quiescent (Iq) 29mA
Output Characteristics OPEN-EMITTER
Prop. Delay@Nom-Sup 0.62 ns
Trigger Type Positive, Negative
Power Supply Current-Max (ICC) 36mA
fmax-Min 2200 MHz
Clock Edge Trigger Type Positive Edge
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
