LMX393AKA
RoHS
/
Package /
Category Integrated Circuits (ICs) / Linear - Comparators
Description
COMPARATOR RoHS Compliant GULL WING AUTOMOTIVE comparator circuit 125C 93.98dB 7000muV 2.9mm
PDF
/
Buying Options
Total Price: USD $17.88
Unit Price: USD $17.87663
≥1 USD $17.87663
≥10 USD $16.864745
≥100 USD $15.910132
≥500 USD $15.00956
≥1000 USD $14.159961
Inventory: 1527
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 1.625mm
Length 2.9mm
Height Seated (Max) 1.45mm
Technical
Input Offset Voltage-Max 7000μV
Bias Current-Max (IIB) @25C 0.25μA
Average Bias Current-Max (IIB) 0.004μA
Voltage Gain 93.98dB
Amplifier Type COMPARATOR
Response Time 600 ns
Supply Current-Max 0.3mA
Min Supply Voltage 1.8V
Max Supply Voltage 5.5V
Temperature Grade AUTOMOTIVE
Power Supplies 3/5V
Output Type OPEN-DRAIN
Pin Count 8
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.65mm
Supply Voltage 2.7V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Comparator
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e3
Packaging Cut Tape
Physical
Number of Pins 8
Mount Surface Mount
Alternative Model
