LTC6401CUD-8#PBF
RoHS
RoHS compliant
RoHS compliantPackage 16-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Linear - Amplifiers - Special Purpose
Description
IC ADC DRIVER 16QFN
PDF
/
Buying Options
Total Price: USD $7.49
Unit Price: USD $7.4888
≥1 USD $7.4888
≥10 USD $6.76456
Inventory: 94
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 2 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case 16-WFQFN Exposed Pad
Surface Mount YES
Number of Pins 16
Technical
Packaging Tube
Published 2007
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Type ADC Driver
Resistance 460Ohm
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Applications Data Acquisition
Subcategory Operational Amplifier
Technology CMOS
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number LTC6401
Pin Count 16
Operating Supply Voltage 3V
Temperature Grade COMMERCIAL
Number of Channels 1
Max Supply Voltage 3.5V
Min Supply Voltage 2.85V
Slew Rate 3400 V/μs
Common Mode Rejection Ratio 36 dB
Input Offset Voltage (Vos) 4mV
Bandwidth 2.22 GHz
Voltage Gain 8.5dB
Power Supply Rejection Ratio (PSRR) 50dB
Nominal Gain Bandwidth Product 2.2 GHz
Dimensions
Height Seated (Max) 0.8mm
Length 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
