TLE2074ACDWR
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Contains Lead Not Qualified GULL WING OPERATIONAL AMPLIFIER op amp buffer circuit 89dB 35V/us 70C 10MHz
PDF
/
Buying Options
Total Price: USD $2.03
Unit Price: USD $2.027302
≥1 USD $2.027302
≥10 USD $1.912555
≥100 USD $1.804295
≥500 USD $1.70216
≥1000 USD $1.605815
Inventory: 1093
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Length 10.3mm
Height Seated (Max) 2.65mm
Technical
Slew Rate-Min 22 V/us
Common-mode Reject Ratio-Min 79 dB
Voltage Gain-Min 8912.5
Input Offset Voltage-Max 5100μV
Neg Supply Voltage-Max (Vsup) -19V
Bias Current-Max (IIB) @25C 0.000175μA
Low-Bias YES
Supply Voltage Limit-Max 19V
Frequency Compensation YES
Low-Offset NO
Average Bias Current-Max (IIB) 0.005μA
Unity Gain BW-Nom 9400 kHz
Neg Supply Voltage-Nom (Vsup) -5V
Gain Bandwidth Product 10MHz
Common Mode Rejection Ratio 89 dB
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Slew Rate 35 V/us
Supply Current-Max 7.5mA
Number of Channels 4
Temperature Grade COMMERCIAL
Power Supplies +-5/+-15V
Operating Temperature (Max) 70°C
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G16
Pin Count 16
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Technology BIFET
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
ECCN Code EAR99
Number of Terminations 16
Pbfree Code no
Physical
Number of Pins 14
Surface Mount YES
Package / Case SOIC
