LMV751M5X
RoHS
/
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description
Non-RoHS Compliant EAR99 LMV751 Tin/Lead (Sn/Pb) op amp amplifier circuit 2.9mm 1.5pA 50muV 4500kHz
PDF
/
Buying Options
Total Price: USD $2.15
Unit Price: USD $2.14795
≥1 USD $2.14795
≥10 USD $1.7632
≥100 USD $1.7081
≥500 USD $1.653
≥1000 USD $1.5979
Inventory: 1195
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Length 2.9mm
Technical
Power NO
Wideband NO
Programmable Power NO
Micropower YES
Low-Bias YES
Frequency Compensation YES
Low-Offset NO
Voltage Gain 120dB
Unity Gain BW-Nom 4500 kHz
Gain Bandwidth Product 5MHz
Input Offset Voltage (Vos) 50μV
Output Current per Channel 20mA
Voltage - Supply, Single/Dual (±) 2.7V~5V
Current - Input Bias 1.5pA
Common Mode Rejection Ratio 100 dB
Amplifier Type General Purpose
Architecture VOLTAGE-FEEDBACK
Slew Rate 2.3V/μs
Output Current 12mA
Nominal Supply Current 500μA
Operating Supply Current 600μA
Number of Circuits 1
Pin Count 5
Base Part Number LMV751
Supply Voltage 2.7V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Operational Amplifier
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount
