MAX9725EEBC+
RoHS
RoHS compliant
RoHS compliantPackage 12-WFBGA, WLCSP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
R-PBGA-B12 Tube Depop Short-Circuit Protection Shutdown DirectDrive? audio amplifier 0.9V 2.02mm 25mW x 2 @ 16Ohm 0.025W
PDF
/
Inventory: 7049
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 1.54mm
Length 2.02mm
Height Seated (Max) 0.67mm
Technical
Max Output Power x Channels @ Load 25mW x 2 @ 16 Ω
Bandwidth 22 kHz
Output Power 0.025W
Number of Channels 2
Supply Voltage-Min (Vsup) 0.9V
Supply Voltage-Max (Vsup) 1.8V
Output Type Headphones, 2-Channel (Stereo)
Qualification Status COMMERCIAL
JESD-30 Code R-PBGA-B12
Pin Count 12
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.5mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form BALL
Terminal Position BOTTOM
Voltage - Supply 900mV~1.8V
Technology BICMOS
Terminal Finish NOT SPECIFIED
Type Class AB
Number of Terminations 12
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Last Time Buy
Pbfree Code no
Feature Depop, Short-Circuit Protection, Shutdown
Series DirectDrive?
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Surface Mount YES
Package / Case 12-WFBGA, WLCSP
Mounting Type Surface Mount
